Creality Sermoon X1 Industrial 3D Scanner | Metrology-Grade Hybrid Laser with Photogrammetry

The Ultimate High-Precision Solution for Industrial Inspection

The Creality Sermoon X1 is an industrial-grade metrology scanner designed for zero-error workflows. Built with a robust CNC-machined monoblock frame, the X1 provides unmatched thermal stability and vibration resistance, ensuring that every micron is captured with absolute confidence.

Why the Sermoon X1 is the New Industry Standard:

• Integrated Photogrammetry & Scale Bars: Unlike standard scanners, the X1 features built-in photogrammetry that uses scale bars to automatically correct dimensional drift. This allows for an incredible volumetric accuracy of 0.02 mm + 0.03 mm/m, making it the top choice for large-scale engineering.
  +1
• Hybrid 4-Mode Scanning: > * 34 Cross Blue Lasers: For rapid, high-efficiency scanning of large surfaces.
  • 7 Parallel Blue Lasers: For capturing ultra-fine, sharp edges and intricate textures.
  • Single Blue Laser Line: Specialized for deep holes and narrow gaps (6:1 depth-to-diameter ratio).
  • Markerless NIR (Near-Infrared): Swift, marker-free scanning for humans or feature-rich objects.
  • Extreme Speed & Performance: Capture data at 90 FPS with a processing rate of up to 1.73 million points per second, significantly reducing time-on-task for large projects like automotive design.
  • All-Environment Adaptability: Capable of scanning in direct sunlight (up to 100,000 lux) and handling shiny or jet-black surfaces without the need for developer spray.
  • Wireless Freedom: Built-in Wi-Fi 6 supports data transfer speeds up to 4.7Gbps, allowing for completely untethered, high-speed scanning when paired with the optional battery handle.

Perfect For: Aerospace Engineering, Automotive Inspection, Large-Scale Artifact Digitalization, and Metrology-Grade Quality Control.
